ANSI CLASS 150, 300, 600 AVAILABLE AS STANDARD. HIGHER PRESSURE CLASS CONSTRUCTION ON REQUEST.

PLEASE CLICK THE LINK BELOW FOR DIMENSIONAL SPECS

DOWNLOAD ENGINEERING SPECS/PDF

CAPABILITIES UNLIMITED.....WITH FSI

www.oscommercewebtemplates.com

Size
in. (mm)

A
in. (mm)

B
in. (mm)

C
in. (mm)

D
in. (mm)

E
in. (mm)

Cover Weight
lb.(kg)

Unit Weight
lb.(kg)

Flanged Butweld

2 (50)

10.00 (254)

5.00 (127)

5.75 (146)

11.00 (279)

12.50 (318)

5 (2)

28 (13)
16(7)

3 (80)

12.25 (311)

6.75 (172)

7.06 (179)

13.75 (349)

15.25 (387)

9 (4)

52 (24)
32(15)

4 (100)

14.25 (362)

8.25 (210)

8.06 (205)

16.25 (413)

18.38 (467)

17 (8)

79 (36)
49(22)

5 (125)

16.75 (425)

9.75 (248)

9.31 (237)

19.25 (489)

21.63 (549)

20 (9)

105 (48)
96(44)

6 (150)

18.25 (464)

11.25 (286)

10.13 (257)

21.25 (540)

23.68 (606)

26 (12)

140 (64)
92(42)

8 (200)

22.00 (559)

14.00 (356)

12.13 (308)

26.00 (660)

29.00 (737)

45 (20)

230 (104)
152(69)

10 (250)

25.00 (635)

17.00 (432)

13.69 (348)

30.00 (762)

33.50 (851)

70 (32)

325 (148)
221(100)

12 (300)

29.00 (737)

20.00 (508)

15.75 (400)

35.00 (889)

39.00 (991)

110 (50)

500 (227)
340(154)

14 (350)

32.00 (813)

22.00 (559)

17.38 (441)

39.00 (991)

43.00 (1092)

140 (64)

710 (322)
490(222)

16 (400)

34.00 (864)

24.00 (610)

18.44 (468)

42.00 (1067)

46.00 (1168)

180 (82)

860 (390)
580(263)

18 (450)

38.00 (965)

27.00 (686)

20.56 (522)

47.00 (1194)

51.50 (1308)

220 (100)

1025 (465)
725(329)

20 (500)

41.36 (1051)

30.00 (762)

22.38 (568)

51.38 (1305)

56.38 (1432)

285 (129)

1350 (613)
990(449)

24 (600)

46.00 (1168)

34.00 (864)

24.88 (632)

58.00 (1473)

63.00 (1600)

430 (195)

2100 (953)
1580(717)
